CATALOG OF PRODUCTS

TMI catalogued products, delineated into 11 definitive casework sections listed below, represent the most common cabinet configurations we see specified across the country.  Utilize TMI product numbers to assist in creating the basis of design and set the quality expectations.  Designing casework elevations utilizing 3" increments in width, as shown in each catalog section, will ensure consistency, and control project costs by establishing manufacturing efficiencies into the finished project.

Select catalog sections to view PDF:
Base Casework
Drawer Casework
Wall Casework
Tall Casework
Music Casework
Specialty Casework
Accessories
Rail-Mounted Casework
Assemblies
Countertops
Office Casework

PRODUCTS OPTIONS

Spellcheck

To help most clearly determine and communicate all of the details involved in the construction of your casework, we have developed the SpecCheck® program.  With one easy to use form, SpecCheck® gives you the freedom to select the specification options recommended by TMI, or to choose from our menu of other popular and proven options.

Request a custom SpecCheck® specification here.





TMI Logo



Laminate Options



TMI sources raw materials from the best vendors in the industry based upon a strict set of requirements including competitive pricing, quality materials, and excellent customer service. As a result we offer our customers high quality finished products which meet their individual design needs and budget requirements.



Select manufacturer to view details:
Formica®
Wilsonart®
Panolam®
Other Laminates
Antimicrobial Options
Spellcheck
Formica Logo

Formica Group is a leading provider of surfacing solutions for commercial customers worldwide. As the world’s largest manufacturer of High Pressure Laminate (HPL), our international network of design, manufacturing, distribution and sales operations maintains the recognition of Formica® as a global brand.

The heritage and brand reputation of the Formica Group of companies has been founded on quality, service and innovative product lines. Our ongoing product design and development process underscores our commitment to innovation.

View the TMI FORMICA LAMINATE color offering (PDF)

Spellcheck
Formica Logo

Wilsonart Engineered Surfaces is a world leading manufacturing and distribution organization that is driven by a mission to create innovative, high performance surfaces people love, with world-class service our customers can count on.

Headquartered in Austin, Texas, Wilsonart manufactures and distributes High Pressure Laminate and other engineered surfaces for use in Institutional markets.

Visit:  www.wilsonart.com

View the TMI WILSONART LAMINATE color offering (PDF)

Panolam crop
nevamar Logo nevamar Logo

Panolam Surface Systems is bringing more to the surface. With their portfolio of brands, customers can find exactly what they need and even discover solutions they never imagined. More choices mean more solutions and time-savings in selecting materials.

Panolam materials are developed to meet the aesthetic criteria of the most demanding architects and designers and to withstand the friction, the impact and ever-changing conditions of life.  Their portfolio of brands and custom solutions provide virtually limitless possibilities.

Visit:  www.panolam.com

Not all laminates are created equal.  Awareness of pricing, availability, lead times, and other manufacturing differences between each of the alternative laminate brands is important when making color selections. TMI will provide the alternative laminates listed below when specified, with colors selected at bid time, and availability does not impact the delivery schedule.

Abet Laminati Logo

ABET Laminati is Europe's largest laminate manufacturer.  Known for colour, texture and patterns, in durable laminate veneers that can be used on a multitude of furniture and other surfaces.  Visit:  www.abetlaminati.com/en/

Arborite Logo

Based in Montreal, Canada, Arborite has been bringing decorative high-pressure laminate to the design community since 1947.  Visit:  www.arborite.com

Lamin Art Logo

Lamin-Art, Inc. is the North American design leader in extraordinary decorative laminate, real wood veneer, and embossed metals.  They became a part of the Wilsonart Engineered Surfaces family in 2016.  Visit:  www.laminart.com

TMI is pleased to offer laminate selections which include Antimicrobial Protection that inhibits the growth of bacteria, mold and mildew that cause stains and odors.  View details.

Wilsonart Logo

Premium & HD® Laminates:

  • Antimicrobial Protection comes standard with no up-charge or special order requirements.
  • Premium & HD® laminates are available in select Wilsonart® colors.

Laminate Finishes -38 and -60:

  • Antimicrobial Protection is available as a special option with a nominal up-charge and may incur additional factory lead time.
  • Finishes -38 and -60 are available in select Wilsonart® laminates.
Formica Logo

Infiniti® Laminates:

  • Antimicrobial Protection comes standard with no up-charge or special order requirements.
  • Infiniti® laminates are available in select Formica® colors.

Aegis Secure® Laminates:

  • Antimicrobial Protection comes standard with no up-charge or special order requirements.
  • Aegis Secure (AS) laminates are available in select Nevamar® and Pionite® colors.




TMI Logo



CORE MATERIAL OPTIONS



TMI sources raw materials from the best vendors in the industry based upon a strict set of requirements including competitive pricing, quality materials, and excellent customer service. As a result we offer our customers high quality finished products which meet their individual design needs and budget requirements.

Select core option to view details:
Particleboard
MDF
ComboCore Plywood
Veneer Core Plywood
TMI Core Material Option - Veneer Core Plywood

Industrial Grade

Particleboard

Meeting or exceeding the American National Standard ANSI A208.1 Grade M2 minimum physical property requirements, TMI particleboards are engineered to succeed in the laminate casework marketplace.

  • Density:  Average 45-50 lbs/ft3
  • Screw Hold Face:  202 lbs.
  • Screw Hold Edge:  180 lbs.

TMI Particleboard is available with attributes including: No Added Formaldehyde (NAF), Moisture Resistant (MR), and with Certified FSC Chain-of-Custody wood (FSC-C018082).

Particleboard is the core material that is recommended by the Architectural Woodwork Institute (AWI) for laminate casework products.

TMI Core Material Option - Medium Density Fiberboard (MDF)

MDF (Medium

Density Fiberboard)

Meeting or exceeding the American National Standard ANSI A208.2 Grade 130 minimum physical property requirements, MDF boards are heavier and more expensive than industrial grade particleboard.

  • Density:  Average 48 lbs/ft3
  • Screw Hold Face:  300 lbs.
  • Screw Hold Edge:  275 lbs.

TMI MDF options are available with attributes including: No Added Formaldehyde (NAF), Moisture Resistant (MR), and with Certified FSC Chain-of-Custody wood.

MDF constitutes a small percentage of TMI production and is not a common core material specified for laminate casework products.

TMI Core Material Option - Combination Fiber Core (CFC) Plywood

Combination

Core Plywood

Combination Core Plywood, also called ComboCore, combines MDF outer faces with veneer core plywood inner-plies.  The MDF surfaces provide a smooth surface to laminate to, while the plywood inner-plies provide the strength of a more traditional plywood application.

TMI recognizes ComboCore Plywood as an exceptional substitution for traditional plywood, with characteristics that contribute to a high quality laminate casework product including:

  • More Stable, Flat, and non-Warping
  • Ability to apply Thermally Fused Laminate (TFL)
  • More Budget Friendly

TMI ComboCore Plywood options are available with attributes including: No Added Formaldehyde (NAF), and with Certified FSC Chain-of-Custody wood.

TMI Core Material Option - Veneer Core Plywood

Veneer Core

Plywood

In the laminate casework industry, traditional veneer core plywood is not recommended as a viable core material by many manufacturers.  The Architectural Woodwork Institute states that plywood will not be warrantied against deflection or delamination when utilized for door and drawer faces.

Veneer core plywoods tend to be unstable, in a manufacturing process which demands a stable, flat laminating surface.  Thickness tolerances are not consistent, where accuracy is measured down to 1/10th of a millimeter.  Thermally fused laminate (TFL) cannot be applied to plywood, in an industry in which cost of finished goods is very important.

When veneer core plywoods are required, TMI recommends 9-ply birch hardwood plywood, or an equivalent plywood solution.





TMI Logo



Design Inspired Pull OPTIONS



A simple but effective way to improve the aesthetic quality of any laminate casework design is through the hardware. Introduced as the TMI Vendor Stock Pull Program, this is the most impressive and complete pull offering available in the industry, from the leader in the laminate casework industry, TMI Systems Corporation. Select from any of the 20 design and finish option combinations. No additional costs*, no extended lead times, no hassles!

*Antimicrobial Pulls will incur higher costs than other Vendor Stock Pull options.

Select pull option to view details:
Contemporary Pull
Bar Pull
Bow Pull
Petite Bow Pull
Heavy Bow Pull
Wire Pull
Semi-Recessed Pull
Antimicrobial Pulls*

TMI CONTEMPORARY PULL

5 1/2" Overall

TMI Pull Option - Contemporary Pull

96mm Hole Spacing

(Nominal 3 3/4")

Color & Finish Options:  Brushed Nickel (shown above).

TMI Laminate Casework Products

TMI BAR PULL

5 1/2" Overall

TMI Pull Option - Bar Pull

96mm Hole Spacing

(Nominal 3 3/4")

Color & Finish Options:  Satin Bronzed Copper, Nickel Matte (shown above), Chrome Polished, and Chrome Matte.

TMI Laminate Casework Products

TMI BOW PULL

4 1/2" Overall

TMI Pull Option - Bow Pull

96mm Hole Spacing

(Nominal 3 3/4")

Color & Finish Options:  Black Matte, Oil Rubbed Bronze, Satin Bronzed Copper, Nickel Matte (shown above), Chrome Polished, and Chrome Matte.

TMI Laminate Casework Products

TMI PETITE BOW PULL

4 1/2" Overall

TMI Pull Option - Petite Bow Pull

96mm Hole Spacing

(Nominal 3 3/4")

Color & Finish Options:  Brushed Nickel (shown above).

TMI Laminate Casework Products

TMI HEAVY BOW PULL

5" Overall

TMI Pull Option - Petite Bow Pull

96mm Hole Spacing

(Nominal 3 3/4")

Color & Finish Options:  Brushed Nickel (shown above).

TMI Laminate Casework Products

TMI WIRE PULL

4" Overall

TMI Pull Option - Wire Pull

96mm Hole Spacing

(Nominal 3 3/4")

Color & Finish Options:  Epoxy powder coated Gray, Beige, White, Slate, Black, Chrome, and Satin Chrome (shown above).

TMI Laminate Casework Products

TMI SEMI-RECESSED PULL

4 1/2" Overall

TMI Pull Option - Wire Pull

2"



Color & Finish Options:  Gray, Beige, White, and Black ABS Plastic.

TMI Laminate Casework Products

TMI ANTIMICROBIAL PULLS

Selecting casework hardware with antimicrobial attributes gives you an additional level of protection that reduces the growth of bacteria, molds and other fungi.  Maintaining an enhanced level of cleanliness on any high-touch surface is as critical today as it has ever been. TMI is pleased to provide these Antimicrobial Pull* options as part of our comprehensive casework and architectural woodwork offering.

Wire

Contemporary

Square

Wire

Bow

Bar

View Antimicrobial Pull Information

Overview Details Specifications

SPECIFICATIONS



TMI Logo



Through a dialogue with architects and extensive product research, we have established specification options which provide optimum durability at the most affordable cost, along with the AutoCAD and Revit details to keep your project documents coordinated with your specifications.

The recommended specifications and details available below contain the results of over 50 years of industry experience and product development



TMI Logo

EDUCATION
SPECIFICATIONS

TMI SPECIFICATIONS:

AUTOCAD DETAILS:

TMI REVIT FAMILIES:

TMI Logo

HEALTHCARE
SPECIFICATIONS

TMI SPECIFICATIONS:

AUTOCAD DETAILS:

TMI REVIT FAMILIES:

TMI Logo

COMMERCIAL
SPECIFICATIONS

TMI SPECIFICATIONS:

AUTOCAD DETAILS:

TMI REVIT FAMILIES:

TMI Logo

LABORATORY
SPECIFICATIONS

TMI SPECIFICATIONS:

AUTOCAD DETAILS:

TMI REVIT FAMILIES:

TMI Logo

MILLWORK
SPECIFICATIONS

TMI SPECIFICATIONS:

AUTOCAD DETAILS:

TMI has resources available to assist in your casework specification language development, with product quality the top priority. We will assist in developing a customized specification based on options you select, or review your existing specification and recommend language updates.



PVC AVAILABILITY

TMI Logo

Color, perhaps more than anything else, has a profound influence on appearance. It not only impacts the casework itself, it directly affects the overall aesthetics of the environment in which the casework is installed. In both 1mm PVC edging and 3mm PVC edging, TMI has matches for solid colors, woodgrains and patterns.

View Matching PVC Availability
